Nonwoven fabric slitter rewinder works with various nonwoven fabric materials for the most streamlined slitting and rewinding processes.
Machine adopts plat steel welding, firmly and balanced, more stable in the high-speed operation.
Features:
1.Feeding with 3 inch air shaft, maximum feeding diameter is 1000mm, with magnetic powder tension controller.
2.Rewinding with 3 inch air shaft and magnetic powder controller, easy to operate, maximum rewinding diameter is 200mm;rewinding aesthetic and neatly.
3.Machine use round knife cutting,60-1300mm adjustable.
Technical Data:
Name:Nonwoven Fabrics Slitter Rewinder
Model:PPD-NWSR1300
Mother roll maximum width: 1300mm
Mother roll outer diameter: max1000mm
Mother roll inner core diameter: 3inch
Slit roll width:60-1300mm(adjustable)
Slit roll inner core diameter: 3inch or as customized size
Slit roll outer diameter: max500mm(optional)
Speed: 0- 300m/min
Power:2.5kw
Voltage:220/380/415V,50Hz
